Piezo Buzzer(External Drive Type) pp-1440H8B

    • Piezo Buzzer(External Drive Type) pp-1440H8B
    • Piezo Buzzer(External Drive Type) pp-1440H8B

Detailed Product Description

Specification



Type

Unit

PP-1440H8

Operating Voltage操作电压

v

Max 25Vp-p

Rated Current(max) 额定电流

mA

3mA (Max)

Sound output at 10cm输出声压

dB

Min 80dB(Typ.)at 5Vp-p,4 khz

Rate Frequency额定频率

Hz

4000

Capacitance电容量

pF

13000±30%

Operating temperature操作温度

-20~+60

Storage Temperature贮存温度

-30~+70

Weight重量

g

0.5

Housing material外壳材质

Mppo

Packing Condition包装情况

5000pcs/box

Value Applying at Rated Voltage(resonant frequency, 1/2 duty,square wave)
